Built around Edelbrock's reputation of bolt-on performance carburetors, the Edelbrock 1151 Vintage 94 series two-barrel 160 CFM primary carburetor provides nostalgic and period correct hot rods and restorations with the most accurate and best performing carburetor on the market. The Edelbrock 1151 vintage 94 series two-barrel 160 CFM primary carburetor features a die-cast bowl and air horn with an aluminum 3-bolt base. In addition, the throttle shafts have been knurled & extended to prevent the linkage arm from slipping and to make it easier to install dual and triple carburetor combinations, especially when used with Edelbrock's exclusive progressive linkage. Extensive testing, both on the road and in our state-of-the-art engine dynamometer facility has allowed Edelbrock to offer a power valve and jetting combination that delivers a wide calibration band for smooth and strong performance in various applications.
Additional Attributes:
- GTIN: 00085347011513
- Adjustable Float Level: No
- Air Cleaner Flange Diameter: 2.625
- Barrel Quantity: 2
- Base Length: 2.6
- Base Width: 3.9
- Body Height: 5.8
- Body Material: Aluminum
- Center Hung Floats: Yes
- Choke Type: Manual
- Finish: Zinc-Dichromate
- Float Level: 1.406
- Float Material: Brass
- Gasket Or Seal Included: Yes
- Grade Type: Performance
- Inlet Fitting Thread Diameter: 0.5
- Linkage Attached: No
- Marine Approved: No
- Maximum Flow Rating: 160
- Mounting Hardware Included: No
- Mounting Hole Diameter: 0.345
- Mounting Hole Quantity: 3
- Primary Jet Diameter: 0.053
- RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
- Spacer Included: No
- Street Legal: No
Extended Information:
- Emissions : EPA Eligible
- Life Cycle Status: Discontinued
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 7 x 7.5 x 6.75 inches
